brick

Le Brick a été dessiné par Jean-Jacques Herbulot, en 1964 à la demande de nombreux clients propriétaires de petits croiseurs côtiers, qui révaient d’un bateau ayant des possibilités d’assez longue croisière pour quatre personnes, tout en restant d’un prix raisonnable. Le programme était : bateau assez rapide à tirant d’eau moyen, hauteur sous barrots, quatre couchettes, une cuisine convenable, une table à carte permettant une navigation sérieuse, et un WC séparé. Après de nombreuses discussions, la longueur a été arrêtée à 7,95 m, la largeur à 2,50 m, le tirant d’eau à la dimension passe-partout de 1,20 m, la voilure à 25 m2 .

Dimensions

Length Beam Length overall Length floatage Beam floatage Beam at harbour Beam on road Add a new line

7.95 m
26' 1"

2.50 m
8' 2"



6.50 m
21' 4"







Modify the line

Keels

Keel type Twin keels Displacement Total ballast Fixed ballast Mobile ballast Liquid ballast Sailing draft Minimal draft Add a new line


Fixed keel



1 800 kg
3968 lb



700 kg
1543 lb





1.20 m
3' 11"



Modify the line

Sails

Form Area Main sail Jib Self tack jib Spi Spi type Add a new line


Marconi

25.35 m²











Modify the line

Mast

Configuration Air space Mast length Mast material Self raise mast Add a new line


Sloop





Wood



Modify the line

Cabin

Cabin type Cabin berths Maxi berths Toilet number Headroom Fore cabin headroom Aft cabin headroom Toilet headroom Add a new line


2 cabins

4



1









Modify the line

Construction

Hull material Existence Start production End production Number build Number build year Price new (euro) Price year Add a new line


Wood

Second-hand production

1964











Modify the line

Homologation / Capacity

Approval certificate Max persons onboard Max load Buoyancy Water tank Petrol tank Engine power In-board motor Add a new line

3















Modify the line

Shipyard Add a new line

Mallard Modify the line

Architect Add a new line

Herbulot Modify the line

Designer Add a new line

Useful links Add a new line

Boats linked Add a new line Click here to have explanations

Image gallery

Comments

Bernard

1 on Feb. 19 2009


Catégorie d'homologation

Je croyais qu'il était en 5ème catégorie. Je viens de recevoir les plans des voiles d'origine pour le mien "inithiael" à pont l'abbé (m'écrire simatai@laposte.net)
