NEPTUN 22

Bonjour à toutes et tous,

Visiblement, le NEPTUN 22 est inconnu de tous. Voilà pourtant un joli bateau logeable, bien construit, sécurisant et surtout idéalement économique pour qui veut tirer ses premiers bords sur l'eau .

Dimensions

Length Beam Length overall Length floatage Beam floatage Beam at harbour Beam on road Add a new line

6.95 m
22' 10"

2.50 m
8' 2"

6.95 m
22' 10"

5.80 m
19' 0"



2.50 m
8' 2"

2.50 m
8' 2"

 Modify the line

Keels

Keel type Twin keels Displacement Total ballast Fixed ballast Mobile ballast Liquid ballast Sailing draft Minimal draft Add a new line


keel +
centerboard



950 kg
2094 lb









1.05 m
3' 5"

0.55 m
1' 10"

 Modify the line

Sails

Form Area Main sail Jib Self tack jib Spi Spi type Add a new line


Marconi

26 m²

10.70 m²

15.30 m²



34 m²


Symetric

 Modify the line

Mast

Configuration Air space Mast length Mast material Self raise mast Add a new line


Sloop



8 m
26' 3"

Alu



 Modify the line

Cabin

Cabin type Cabin berths Maxi berths Toilet number Headroom Fore cabin headroom Aft cabin headroom Toilet headroom Add a new line


1 cabin

2

5



1.85 m
6' 1"







 Un système de levage du capot sur parallélogramme permet , au port, de jouir d'une hauteur sous barrot de 1,85m dans le carré. Très sympa.Modify the line

Construction

Hull material Existence Start production End production Number build Number build year Price new (euro) Price year Add a new line


Polyester monolit.

Second-hand production

1976











 Le bateau est partiellement contremouléModify the line

Homologation / Capacity

Approval certificate Max persons onboard Max load Buoyancy Water tank Petrol tank Engine power In-board motor Add a new line







Insubmersible

30 l

25 l

8 HP



 Moteur 8cv/ 4T Yamaha en puits.Modify the line

Shipyard Add a new line

Alexander Dimitrow Modify the line

Architect Add a new line

Miglitsch Anton Modify the line

Designer Add a new line

Mitgllisch Modify the line
